NEW Tab on Road Signs

Have you ever noticed a small rectangular sign with the word NEW mounted beneath a traffic sign in British Columbia? It is intended to catch your attention and alert you to a change in the traffic controls ahead.

The sign is known as the W-329 NEW tab. It is a British Columbia-specific traffic sign. You will not find this particular tab in the standard traffic sign systems used in other Canadian provinces or in the United States, although other jurisdictions have their own ways of warning drivers about new traffic controls and changed traffic patterns.

British Columbia's W-329 NEW Tab

British Columbia W-329 NEW tab showing the word NEW on a yellow panel surrounded by black rays on a white background

The W-329 is a rectangular tab with a white background, black rays radiating around its edge and a yellow panel behind the word NEW. Its purpose is to make a driver more likely to notice a traffic control that has recently been installed or changed.

Drivers who regularly travel the same route can become accustomed to the signs, signals and road layout they encounter. A new stop sign, traffic signal or restriction can be overlooked simply because it was not there the last time they travelled through the area. The NEW tab is intended to interrupt that expectation and encourage drivers to pay attention.

The W-329 is not a separate traffic regulation. It draws attention to the sign or traffic control beneath it. Drivers must still obey the underlying sign or signal, whether or not a NEW tab is present.

When Is the W-329 Used?

The older BC Manual of Standard Traffic Signs and Pavement Markings says the W-329 should be used with the W-12 SIGNAL AHEAD sign for new traffic signal installations. It also says the tab may be used with any other standard sign to draw attention to revisions in traffic control.

The current BC Traffic Controller Design Manual, Section 400, provides more specific instructions for new and modified signal installations.

New traffic signal installations

When a new traffic signal is commissioned, permanent SIGNAL AHEAD signs (W-012) may be installed where appropriate. If permanent advance warning signs or advance warning flashers are not installed, temporary C-112 SIGNAL AHEAD signs are required.

Temporary W-329 NEW tabs are to be installed beneath each permanent W-012 or temporary C-112 sign as part of this commissioning process. Where the temporary C-112 and W-329 signs are not part of the permanent installation, the electrical maintenance contractor must remove them after 90 days unless the Ministry Traffic Engineer directs otherwise.

Changes to existing traffic signals

Changes to an existing signal can also affect the way drivers must respond. For example, the signal phasing may change, or the intersection layout may be modified by adding a turn lane or changing a through lane into a shared through lane.

The current design manual requires temporary C-064 SIGNAL OPERATION CHANGED signs in advance of each approach when signal phasing changes. C-063 TRAFFIC PATTERN CHANGED signs may be used instead when the signal operation remains the same but the roadway geometry changes.

Temporary C-063, C-064 and W-329 signs that are not part of the permanent installation are to be removed after 90 days unless otherwise directed. This is not a general requirement that every W-329 sign used in every circumstance must be displayed for 90 days.

What About New Speed Limits and Other Traffic Signs?

The older BC sign manual permits the W-329 to be used with any standard sign to draw attention to a revision in traffic control. This provides flexibility for road authorities to use the tab when a change might otherwise go unnoticed.

However, that does not mean a W-329 must be installed every time a speed limit changes or a new traffic sign is erected. The specific requirements in the current signal-design manual apply to the signal installations and modifications described above. Use in other situations is a matter for the responsible road authority.

For example, a change in a speed limit is communicated by the new regulatory speed limit sign. A NEW tab might draw additional attention to that change, but the tab is not what establishes the speed limit.

How Other Jurisdictions Alert Drivers to Changes

British Columbia's W-329 is not used throughout Canada or in the United States. Other jurisdictions have developed different signs to serve a similar purpose. The designs and the circumstances in which they are used are not identical.

Ontario: Wb-3 NEW sign

Ontario Wb-3 NEW warning sign, a yellow circular sign with a red centre and white NEW lettering

Ontario uses a distinctive circular Wb-3 NEW sign. It has a red centre with white lettering and a yellow outer area with a black sunburst pattern.

The Ontario Traffic Manual, Book 6: Warning Signs (2001), describes its use with advance warning signs for new STOP, YIELD and traffic signal installations. It also addresses changes to intersection right-of-way control and significant changes to signal timing phases. The manual specifies installation periods for these applications.

United States: new traffic pattern and signal operation signs

United States MUTCD W23-2 NEW TRAFFIC PATTERN AHEAD warning sign

The United States uses a yellow diamond-shaped W23-2 NEW TRAFFIC PATTERN AHEAD sign to warn of changes such as revised lane use or roadway geometry.

United States MUTCD W23-2a NEW SIGNAL OPERATION AHEAD warning sign

A second sign, W23-2a NEW SIGNAL OPERATION AHEAD, warns drivers approaching a signalized intersection that the signal phasing has changed.

The United States Manual on Uniform Traffic Control Devices, Section 2C.38, permits these signs for the purposes described. It recommends removing them when the changed traffic pattern is no longer considered new, when the pattern returns to normal, or within 12 months.

These examples show that the underlying safety concern is shared: drivers may not recognize a change to a familiar road or traffic control. The signs used to address that concern differ from one jurisdiction to another.

What Should Drivers Do?

When you see a NEW tab or one of the comparable warning signs, treat it as a reason to pay particular attention to the traffic control ahead.

  • Look carefully at the sign or signal the tab accompanies.
  • Check for a new stop, yield or traffic signal requirement.
  • Pay attention to changed lane markings, turn lanes and permitted movements.
  • Reduce speed if necessary so you have time to understand and respond to the change.

Do not assume that a familiar intersection still operates the way it did the last time you drove through it. A change may affect who has the right of way, which lane you must use or whether a particular movement is permitted.

Who Decides When to Use a NEW Tab?

Traffic signs and signals are installed and maintained by the road authority responsible for the roadway. On provincial highways, that is generally the BC Ministry of Transportation and Transit. Municipalities are responsible for traffic control on roads under their jurisdiction.

The road authority determines the appropriate traffic control for a particular location and follows the applicable standards and engineering guidance. The W-329 is one tool available to draw attention to a change; it is not a universal requirement for every new or revised sign.
